Orion 24/12-80 DC-DC Converter IP20

Remote on/off connector

The remote on/off eliminates the need for a high-current switch in the input wiring. The remote on-off can be operated with a low-power switch or by the engine run/stop switch (see manual).

All models with adjustable output can also be used as a battery charger. For example, to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models with adjustable output can be paralleled to increase the output current. Up to five units can be connected in parallel.

Specifications:

• Charger Input - Voltage: 24VDC
• Charger Output - Amps: 80A
• Charger Output Voltage: 12VDC
• Box Dimensions: 3"H x 4"W x 9"L WT: 2.3 lbs
• UPC: 8719076069614
